HP4E
Details https://www.akg.com/Headphones/Headphone%20Amps/HP4E.html?dwvar_HP4E_color=Black-GLOBAL-Current4-channel headphone amplifier
Variations
4-channel headphone amplifier
Small footprint
With 4 totally independent stereo high-power amplifiers in half 1 RU package
Carefully selected components
For high quality audio even at extremely high volume levels
Two stereo inputs
For full flexibility with independent selection of input for each output
Two outputs per channel
With each a 1/4” (6.3mm) and 1/8” (3.5mm) stereo socket so no adapter is needed
Rugged construction
With strong metal housing to withstand rough working environments
The ideal compact headphone amp
The HP4E professional headphone amplifier features two stereo input and four stereo output channels of high-quality audio. Designed for ease of use, convenient switches on the front plate enable you to select your designed input. Each channel features both a 1/8” (3.5 mm) and 1/4” (6.3 mm) headphone output for easy connectivity – no adapters required. Housed in a sturdy metal chassis, the HP4E is an ideal headphone amp for any recording session. Available in the US only.
Item#
3450H00010
General Specifications
Design
4-Channel Headphone Amplifier
Input
6.3 mm (1/4”) socket - unbalanced
Input impedance
100k Ohms
Output
3.5 mm (1/8”) socket and 6.3 mm (1/4”) socket per channel
Output impedance
11 Ohms
Audio frequency bandwidth
20 - 20000 Hz
Max. output level
220 mW
Distortion
<0.05%
Signal to Noise
better than 85 dB-A
Net weight (incl. power supply)
760 g
- 1 x HP4E
- 1 x Power Supply (12V)
- 1 x Quick Set Up Guide
