• New
JBL

JBL 104-BT (Pair)

Details
Variations

Compact Desktop Reference Monitors with Bluetooth

$179.00179.0 each
Product Actions
Add to cart options
+

In stock and ready to ship

UPS-BOX Order within 00 hrs 43 mins with Ground Shipping and receive by Wed, Jul 15
Your zip code 20149 edit | Want it faster?
Legendary Sound - No Strings Attached

JBL 104-BT compact reference monitors with Bluetooth, the newest models in the 1 Series line, draw from seven decades of JBL Professional engineering to deliver the truest, most accurate sound in their class. They’re perfect for recording musicians, producers, podcasters and vloggers, as well as professional audio engineers seeking an accurate portable reference with Bluetooth streaming. JBL 104-BT Reference Monitors combine a powerful coaxial 4.5-inch (118 mm) low-frequency driver and .75-inch (19 mm) soft-dome tweeter, potent integrated 60-watt amplification and an innovative acoustic design to reproduce honest sound with exceptional imaging and crisp detail. Bluetooth streaming lets you check mixes over Bluetooth to make sure they sound great in every listening scenario. Both the black 104-BT and white 104-BTW versions are sleek, elegant designs and compact form factors, making stunning statements in any studio while conserving valuable work space. Creative professionals, music lovers and anyone who wants the flexibility to stream both wired and wireless sound into high-quality studio monitors can count on JBL 104-BT to provide an accurate, reliable sonic reference and a truly enjoyable listening experience.

Item# 104SET-BT-US

Device Compatibility

Bluetooth Yes

General Specifications

Bluetooth Version 5.0
Low Frequency Transducer 4.5 in (118 mm)
High Frequency Transducer 0.75 in (19 mm), soft dome
Crossover 1725 Hz, 1st order
Power Amp 60 W (30 W each speaker), Class D
Sensitivity 87 dB SPL @ 1 m with -10 dBV Aux In (Volume = Max)
Maximum Continuous SPL 89 dB
System Peak SPL 102 dB (pink noise, 12 dB crest factor)
Maximum SPL, Momentary Peak 104 dB
Maximum Peak Input Level (-10 dBV / +4 dBu): +6 dBV / +20.3 dBu
Frequency Range (-3 dB SPL) 88 Hz – 20 kHz
Frequency Range (-10 dB SPL) 60 Hz – 20 kHz
System Rated Impedance 8 Ω
Minimum Impedance 7.8 Ω @ 260 Hz
Cabinet Tuning Frequency 72 Hz
System Distortion Criteria <10% THD at maximum output with full compressor / limiter engagement
Electrical Distortion Criteria <0.2%THD @ 1 kHz, 2.83 VRMS output; <1% THD @ 1 kHz, full rated output
Signal to Noise Ratio 75 dBA (A-Weighted), 70 dBr (unweighted), relative to 2.83 VRMS output on HF
Coverage (Horizontal x Vertical) 120º x 60º
Acoustic Test Specification ATS# 1000340443

Dimensions

Height 9.72 in (247 mm)
Width 6.02 in (153 mm)
Depth 4.88 in (124 mm)
Net Weight Primary Monitor = 4.54 lb (2.06 kg); Secondary Monitor = 3.81 lb (1.73 kg)

Design

Enclosure Type Ported
Enclosure Material ABS with metal grille
Enclosure Finish Matte black acrylic paint (104-BT) ; Matte white acrylic paint (104-BTW)

Audio Output

System Output Type 1/8" stereo headphone with auto speaker mute

Audio Input

System Input Type Bluetooth, 1/8" Aux, RCA, 1/4" TRS balanced
Input Selection Options Bluetooth, Aux, RCA, TRS, All

Powering Interface

System Power Handling 30 W x 2 @ 100 hours, IEC/SMS
System Polarity EIA
AC Input Voltage 100 – 240 VAC (± 10%), 50/60 Hz
Current Draw 85 watts
Electrical Current Draw (W) Idle 100 / 240 VAC 3.52 / 3.70
Electrical Current Draw (W) Max Power 100 / 240 VAC 80 / 80
Electrical Current Draw (W) Low Power Standby Mode 100 / 240 VAC 0.34 / 0.46
  • 1 x 104-BT Master Monitor
  • 1 x 104-BT Extension Monitor
  • 1 x Extension monitor speaker wire (2-conductor, 2 meters)
  • 1 x 3.5 mm to RCA audio cable
  • 1 x Regional power cable
  • 1 x Quick setup guide
Product Box
